Cylinder arrangements
Pit depth, water table and travel height decide the arrangement before ride quality is ever discussed.
Hydraulic lift specialists
Anyone can fit a lift into a building designed for one. Hydraulic work earns its keep in buildings that were not — occupied structures, uncertain water tables, roofs that were never meant to carry a machine room. The team has taken on that kind of survey repeatedly across Delhi NCR, choosing between direct-acting, telescopic and roped arrangements based on what the pit and structure actually allow, not what is easiest to quote. That is the judgement building owners are really paying for when they call us for a hydraulic lift.
Choosing it
Hydraulic lifts are frequently specified for the wrong reason — low equipment cost — and then disappoint on speed and running cost. These are the honest tests.
Above that, the ram becomes impractical and a traction or MRL lift is both faster and cheaper to run. This is the first question, and it is often decisive.
If the building is finished, or the roof was never designed for it, hydraulic removes the problem entirely by loading the pit instead.
Oil heats up as the pump works. Above roughly 45 starts per hour the tank needs cooling, and past that the drive type should be reconsidered.
For heavy loads at low rise — car lifts, freight platforms — hydraulic is comfortably the strongest option available.
It needs a small ventilated room within about 10 m of the shaft. Not overhead, which is the flexibility people are usually buying.
A direct-acting ram needs a bored well below the pit. Where groundwater is high, specify a telescopic cylinder instead.
Where they go
Alongside
Equipment is half the decision. These are the parts of the lifecycle we cover for it.
Common questions
Hydraulic elevator price is generally the lowest of the common drive types for equipment cost, which is why it is the default recommendation for retrofits and low-rise work. The figure moves with rated load, cylinder arrangement (direct-acting versus telescopic) and travel height. Running cost is higher than traction over the life of the lift, which is worth weighing against the lower upfront price.
Practically, about 18 m or six floors. Beyond that the ram becomes unwieldy and the running cost is hard to justify against a traction or MRL lift.
Speed is limited by pump flow rate going up, and by controlled oil release coming down. Typical speeds are 0.15 to 0.63 m/s against 1 m/s or more for traction.
Seals wear and eventually weep, which is why seal condition is a standard AMC check. A well-maintained unit should not drip, and a unit that does needs attention rather than topping up.
The car descends to the nearest landing on its own weight through a manual or battery-operated lowering valve, and the doors open. No generator is needed.
The equipment usually is. The running cost is not — a hydraulic lift draws significant power on every up trip, where a counterweighted traction lift only moves the difference.
Send the floor count, the travel height and what sits above the shaft. We will tell you whether hydraulic is the right drive or whether MRL serves you better.
